1. Type-C, DC5V input port, current is 1A (max)
2. The red light of the two-color indicator light is always on when charging, and the blue light of the two-color indicator light is always on when the battery is fully charged.
3. Short press the start button, the fan and spray will start at the same time (the first fan is activated by default), short press again to adjust the fan position, press once to increase the gear, when it reaches the third gear, press the button again to turn off the fan and spray .Three-color indicator light shows the gear position, the first gear is red, the second gear is green, and the third gear is blue; the pure white indicator is the spray working indicator, and the pure white indicator is on when the spray is started.
4. In the case of starting, short press the spray button to turn off the spray. The pure white indicator light goes out, short press the spray button again, the spray is turned on and the pure white indicator light is on. (a. When the fan is not turned on, the spray cannot be turned on. B. Turn off the fan and the spray will be turned off).
5. When the sensor board detects that there is no water, the spray stops working.
6. Short press the light button, RGB lights up, long press the light button to fix the color, short press again to turn off RGB.
7. When there is no external power supply, when the battery is low, the charging indicator will flash red quickly until the fan stops working and the red light goes out.
8. Parameters:
Input voltage: DC5V
Charging current: 1A
Working current: 0.2A-1.6A
Working power: 1W-8 W
Standby current: 88uA
Motor speed: 1700rpm, 2185rpm, 2675rpm
Wind speed: 1.57m/s~2.71m/s
Water usage time: 12h
Battery life: 1.5h~5h
Fan current consumption: 0.24A, 0.48A, 0.9A
